Material: | Aluminium Ally | Power: | Pneumatic |
---|---|---|---|
Structure: | Piston Cylinder | Maximum Stroke: | 19.5mm |
Max Bore: | 50mm | Max Clamping: | 80kgs |
Warranty: | 1 Year | ||
High Light: | destaco pneumatic clamps,destaco swing clamps |
Air Swing Clamp Cylinder induction type Max Bore 50mm Max Clamping 80kgs
Bore of Cylinder (mm)
|
25 short stroke
|
25
long stroke
|
32 short stroke
|
32 long stroke
|
40 short stroke
|
40 long stroke
|
50 short stroke
|
50 long stroke
|
Swing Stroke (mm)
|
9.5
|
9.5
|
15
|
15
|
15
|
15
|
19
|
19
|
Clamping stroke
|
10
|
20
|
10
|
20
|
10
|
20
|
20
|
50
|
Total stroke
|
9.5
|
29.5
|
25
|
35
|
25
|
35
|
39
|
69
|
Bore of Pison
|
?14
|
?16
|
?16
|
?20
|
||||
Fluid
|
Filtered air
|
|||||||
Rotating direction
|
Turn right R or Turn left L
|
|||||||
Acting type
|
Double acting
|
|||||||
Theoretical Clamping ( 5 kg/cm ?2;)
|
16kgs
|
30kgs
|
50kgs
|
80kgs
|
||||
Pressure area pull/push cm ?2;cm?2;
|
3.37/4.9
|
6.03/8.03
|
10.56/12.56
|
16.48/19.62
|
